Description
Highlight Features
- Build ultra-fast network with Wi-Fi 6 technology.
- Client connections over 500, better multi-user experience.
- Provide higher practical performance for users as well.
- Easily install extra AP with Reyee Mesh technology.
- Set up Wi-Fi 6 network in 3 minutes with Ruijie Cloud AP
Hardware Specifications
Wi-Fi Radio
Radio design
- Dual-radio :4 spatial streams
● 2.4 GHz: 2 x 2, MU-MIMO
● 5 GHz: 2 x 2, MU-MIMO
Maximum wireless data rate
- 1774 Mbps
6 GHz wireless data rate
- No
5 GHz wireless data rate
- 1201 Mbps
2.4 GHz wireless data rate
- 573 Mbps
Antenna
Antenna
- 2.4 GHz: 2 built-in omnidirectional antennas
5 GHz: 2 built-in omnidirectional antennas
Dimensions and Weight
Product dimensions (W x D x H)
- 194 mm x 194 mm x 35 mm (7.64 in. x 7.64 in. x 1.38 in.) (excluding the mounting bracket)
Color
- White
Weight
- ≤ 0.55 kg (1.21 lbs.) (without packaging materials)
Port Specifications
Number of 10/100/1000BASE-T ports
- 2
Power Supply and Consumption
Power supply
- ● DC power adapter
● PoE/PoE+
Note: If both the DC power adapter and PoE/PoE+ are available for power supply, the DC power adapter is preferred.
Local power supply
- Yes, one DC power connector (12 V, 1.5 A)
Dimensions of the DC connector
- Outer diameter: 5.5 mm (0.22 in.)
Inner diameter: 2.1 mm (0.08 in.)
Depth: 10 mm (0.39 in.)
PoE budget
- No
Maximum power consumption
- 15.5 W
Environment and Reliability
Operating temperature
- 0°C to 40°C (32°F to 104°F)
Mounting options
- Ceiling/Wall
IP rating
- IP41
Software Specifications
WLAN
Maximum number of associated wireless clients
- 64 (2.4 GHz)
256 (5 GHz)
256 (2.4 GHz and 5 GHz enabled)
Maximum number of devices that can be managed
- 300
IP Service
IPv6
- Yes
